Ein Ansatz zur Protokollierung des Mailverkehrsvolumens in einer Datenbank.
mailtrafficd.pl
MailTrafficD.pm
Config.pm
DB.pm
Milter.pm
mailtrafficd.pl
Perl:
#!/usr/bin/perl
#
# The mailtrafficd program is a Perl-based email traffic logger
# that integrates with Postfix to monitor email traffic on a server.
# It records details such as the sender, recipient, timestamp,
# size of each email and the number of recipients processed by the server
# into a MySQL database.
#
# The program operates as a Milter (Mail Filter) and can be run in
# the background. It uses a persistent database connection to
# efficiently log emails. The program can also toggle terminal
# output for logging, allowing for easy monitoring or quiet operation.
#########################################################################
# Prerequisites:
#
# sudo apt install libsendmail-pmilter-perl
#
# Configure MySQL credentials:
# nano ./lib/MailTrafficD/Config.pm
#
# Postfix:
# sudo nano /etc/postfix/main.cf
#
# with RSPAMD
# smtpd_milters = inet:localhost:11025 inet:localhost:11332
# non_smtpd_milters = inet:localhost:11025 inet:localhost:11332
#
# without RSPAMD
# smtpd_milters = inet:localhost:11025
# non_smtpd_milters = inet:localhost:11025
#
# Restart Postfix:
# sudo service postfix restart
#
# Start Milter:
# nohup ./mailtrafficd.pl & >/dev/null &
#
# Stop Milter:
# kill $(pgrep -f mailtrafficd.pl)
#
# Folder structure:
#
# mailtrafficd/
# ├── lib/
# │ ├── MailTrafficD.pm
# │ ├── MailTrafficD/
# │ │ ├── Config.pm
# │ │ ├── DB.pm
# │ │ └── Milter.pm
# └── mailtrafficd.pl
#
# Don't run that script as root!
###############################################################
use strict;
use warnings;
use lib 'lib';
use IO::Socket::INET;
use MailTrafficD;
use MailTrafficD::Milter;
use MailTrafficD::DB;
use MailTrafficD::Config qw($milter_port);
sub check_port {
my $port = shift;
my $socket = IO::Socket::INET->new(
Proto => 'tcp',
LocalAddr => 'localhost',
LocalPort => $port,
Listen => 1,
Reuse => 1,
);
if ($socket) {
close($socket);
return 0;
} else {
return 1;
}
}
if (check_port($milter_port)) {
die "Port $milter_port is already in use. Program will terminate.\n";
}
# Get the database handle from MailTrafficD
my $dbh = MailTrafficD::get_dbh();
if ($dbh) {
MailTrafficD::DB::create_table_if_not_exists($dbh);
MailTrafficD::Milter::initialize_milter(); # Initialize the Milter
} else {
die "Failed to connect to the database, terminating program.\n";
}
# At the end of the program, disconnect the DB handle
END {
MailTrafficD::disconnect_dbh();
}
MailTrafficD.pm
Perl:
package MailTrafficD;
use strict;
use warnings;
use MailTrafficD::DB;
my $dbh;
sub get_dbh {
return $dbh if $dbh;
# Establish the connection only if it doesn't already exist
$dbh = MailTrafficD::DB::connect(0);
return $dbh;
}
sub disconnect_dbh {
if ($dbh) {
$dbh->disconnect();
undef $dbh;
}
}
1;
Config.pm
Perl:
package MailTrafficD::Config;
use strict;
use warnings;
use Exporter 'import';
# Export only the necessary variables
our @EXPORT_OK = qw($db_name $db_host $db_user $db_pass $enable_terminal_output $milter_port);
# Database connection details
our $db_name = "database_name";
our $db_host = "localhost";
our $db_user = "database_user";
our $db_pass = "database_password";
# Milter configuration
our $milter_port = 11025;
# Option to enable or disable terminal output
our $enable_terminal_output = 0; # Set to 1 to enable, 0 to disable
1;
DB.pm
Perl:
package MailTrafficD::DB;
use strict;
use warnings;
use DBI;
use Try::Tiny;
use MailTrafficD::Config qw($db_name $db_host $db_user $db_pass $enable_terminal_output);
sub connect {
my $dbh;
try {
$dbh = DBI->connect(
"DBI:mysql:database=$db_name;host=$db_host",
$db_user, $db_pass,
{
'RaiseError' => 1,
'PrintError' => 0,
'mysql_auto_reconnect' => 1 # Enable auto-reconnect
}
);
print "Successfully connected to database $db_name.\n" if $enable_terminal_output;
} catch {
die "Error connecting to database: $_";
};
return $dbh;
}
sub create_table_if_not_exists {
my $dbh = shift;
my $table_exists = 0;
try {
my $sth = $dbh->prepare("SHOW TABLES LIKE 'mail_trafficd'");
$sth->execute();
$table_exists = $sth->fetch();
} catch {
warn "Error checking for existing table 'mail_trafficd': $_" if $enable_terminal_output;
};
unless ($table_exists) {
my $sql = qq{
CREATE TABLE mail_trafficd (
id INT AUTO_INCREMENT PRIMARY KEY,
timestamp DATETIME NOT NULL,
sender VARCHAR(255) NOT NULL,
recipient VARCHAR(255) NOT NULL,
recipient_count INT NOT NULL,
email_size INT NOT NULL
);
};
try {
$dbh->do($sql);
print "Table 'mail_trafficd' successfully created.\n" if $enable_terminal_output;
} catch {
warn "Error creating table 'mail_trafficd': $_" if $enable_terminal_output;
};
} else {
print "Table 'mail_trafficd' already exists.\n" if $enable_terminal_output;
}
}
1;
Milter.pm
Perl:
package MailTrafficD::Milter;
use strict;
use warnings;
use Sendmail::PMilter qw(:all);
use MailTrafficD;
use MailTrafficD::Config qw($enable_terminal_output $milter_port);
use POSIX qw(strftime);
use Try::Tiny;
sub initialize_milter {
my $milter = Sendmail::PMilter->new();
$milter->setconn("inet:$milter_port\@localhost");
$milter->register('mailtrafficd', {
envfrom => \&cb_envfrom,
envrcpt => \&cb_envrcpt,
header => \&cb_header,
body => \&cb_body,
eom => \&cb_eom,
});
try {
$milter->main();
} catch {
die "Error starting Milter service: $_";
};
}
sub cb_envfrom {
my ($ctx, $envfrom) = @_;
$ctx->setpriv({ email_size => 0, envfrom => $envfrom });
return SMFIS_CONTINUE;
}
sub cb_envrcpt {
my ($ctx, $envrcpt) = @_;
my $email_data = $ctx->getpriv();
push @{$email_data->{envrcpt}}, $envrcpt;
$ctx->setpriv($email_data);
return SMFIS_CONTINUE;
}
sub cb_header {
my ($ctx, $headerf, $headerv) = @_;
my $email_data = $ctx->getpriv();
$email_data->{email_size} += length($headerf) + length($headerv) + 4;
$ctx->setpriv($email_data);
return SMFIS_CONTINUE;
}
sub cb_body {
my ($ctx, $body_chunk) = @_;
my $email_data = $ctx->getpriv();
$email_data->{email_size} += length($body_chunk);
$ctx->setpriv($email_data);
return SMFIS_CONTINUE;
}
sub cb_eom {
my ($ctx) = @_;
my $email_data = $ctx->getpriv();
my $email_size = $email_data->{email_size};
my $envfrom = $email_data->{envfrom};
my $envrcpt = join(" ", @{$email_data->{envrcpt}});
my $recipient_count = scalar @{$email_data->{envrcpt}};
$envfrom =~ s/[<>]//g;
$envrcpt =~ s/[<>]//g;
my $dbh = MailTrafficD::get_dbh(); # Get the global DB handle
my $datetime = strftime("%Y-%m-%d %H:%M:%S", localtime);
try {
my $sth = $dbh->prepare("INSERT INTO mail_trafficd (timestamp, sender, recipient, email_size, recipient_count) VALUES (?, ?, ?, ?, ?)");
$sth->execute($datetime, $envfrom, $envrcpt, $email_size, $recipient_count);
if ($enable_terminal_output) {
print "Database entry added: timestamp=$datetime, sender=$envfrom, recipient=$envrcpt, email_size=$email_size bytes, recipient_count=$recipient_count\n";
}
} catch {
warn "Error adding entry to the database: $_" if $enable_terminal_output;
};
return SMFIS_CONTINUE;
}
1;
